Phoenix Air 4050

  • Easy to operate
  • Easy to maintenance
  • Friendly for beginners
  • Desk-top version but efficient
  • Lower heating system
  • Build-in Air Purifier

Phoenix Air 4050 DTF Oven with Air Purifier

Phoenix Air 4050 oven was developed by the experience we had with Phoenix oven ,to make an oven which would be less power consumption ,even heating and more stable for curing are the key when we were developing . Finally ,the lower heating system with gas spring lifting help us achieve the goal and it make our Phoenix Air 4050 oven be very popular among all the DTF sheeting printing users by the over the level value it brings to users!

Phoenix Air DTF Oven
Phoenix Air DTF Oven

Benefits:
1. Power saving and more stable curing
2. Build in Air Purifier -Save space & money

Compatible with:
1. Seismo 20
2. All the DTF sheeting printing Process

Please Note: The filters (Activated Carbon & HEPA Filter) in the top smoke purifier need to be replaced periodically for optimal performance. If used for more than 2 hours daily, it is recommended to replace the filters every month.

Activated Carbon Filter
Activated Carbon Filter
HEPA Filter
HEPA Filter



Galaxy Phoenix Air Detail 1

Specification

ModelPhoenix Air 4050
Item No.D.01.01.0013-110V/ D.01.01.0014-220V
Power Requirements1000W, 110V/220V
Max Baking Size40*50cm (38*48 in full image printing)
Temperature Range0-150℃ (0-302℉)
Product Weight13.8kg
Packaging Weight17kg
Machine Dimensions770*534*196mm
Packaging Dimensions815*590*255mm
WarrantyOne year warranty on the entire machine
Suitable UsersAll DTF sheet printing user

Video



1. How to use the Phoenix Air Oven | DTF Station


2. Introducing Phoenix Air | DTF Station





3. Heating UP! Phoenix Air Curing Oven
